| Part Number | Number of Drivers | Input Compatibility | Input Voltage (Max)(V) | Collector to Emitter Voltage Rating(V) | Output Voltage (Max)(V) | Output Current (Max)(mA) | Delay Time (Typ)(ns) | Operating Temperature Range, Ta (℃) | Package Outline | Download |
|---|---|---|---|---|---|---|---|---|---|---|
| ULN2003C | 7 | 5V TTL, CMOS | 30 | 50 | 50 | 500 | 250 | -40~105 | SO-16 PDIP-16 |
|
| ULN2002C | 7 | 14~25V PMOS | 30 | 50 | 50 | 500 | 250 | -40~105 | SO-16 PDIP-16 |
|
| ULN2004C | 7 | 6~15V, CMOS, PMOS | 30 | 50 | 50 | 500 | 250 | -40~105 | SO-16 PDIP-16 |
